Opis
FURMAN P-2300 IT E
Panel zasilający przeznaczony do montażu w skrzyniach rack
- Symetrycznie równoważona moc eliminuje zakłócenia do możliwie najniższego poziomu
- Ochrona przed udarem prądowym SMP
- Ochrona przed przepięciem EVS
- Technologia filtrów liniowych LiFT
- Diodowy wskaźnik samokontroli napięcia
- Cyfrowy woltomierz/amperomierz wyświetlający napięcie i pobór prądu
- Wyseparowanie grup gniazd minimalizujące wzajemny wpływ zasilanych urządzeń
- Zasilające gniazdo USB
- Zabezpieczenie prdowe 10A
- 14 gniazd wyjściowych (12 na panelu przednim plus 2 na panelu tylnym)
OPIS PRODUCENTA:
Symmetrically Balanced Power
Symmetrically balanced power virtually eliminates common mode noise for the lowest noise floor possible.
Surge Protection
Furmans exclusive SMP technology provides the highest level of surge & spike protection available.
Noise Filtration
LiFT offers AC power filtering to ensure clean power for unequaled audio & video clarity.
Voltage Protection
Advanced EVS circuitry detects dangerous voltage irregularities and safely powers down itself and connected equipment in unsafe conditions.
Diagnostic Lights
Protection OK, Extreme Voltage and color-coded voltage range indicators provide information on power quality and operational status of unit.
Voltmeter / Ammeter
Large LED voltmeter/ammeter displays incoming voltage and output current draw.
Isolated Banks
Isolated outlet banks minimize inter-component interference and noise contamination.
USB Charger
Front panel USB convenience outlets allows you to charge most media devices or power a USB lamp.
10 Amp Rating
10 amp rating featuring a high inrush magnetic circuit breaker for added protection.
14 Total Outlets
14 total outlets (twelve rear panel outlets and two front panel convenience outlet).
|
Maximum Current: |
10 amps |
|
Line Cord: |
Detachable cord, 1mm² x 3, 2.5M long, Schuko plug to IEC C13 |
|
Operating Voltage: |
180 to 244 VAC, 50 Hz |
|
Over-Voltage Shutdown: |
275 VAC Nominal |
|
Spike Protection Mode: |
Line to neutral, zero ground leakage |
|
Spike Clamping Voltage: |
375 VAC peak @ 3,000 Amps |
|
Response Time: |
1 nanosecond |
|
Maximum Surge Current: |
6,500 Amps |
|
Noise Attenuation: |
10 dB @ 10 kHz, 40 dB @ 100 kHz, 50 dB @ 500 kHz |
|
Dimensions: |
483mm W x 356mm D x 133mm H (19 W x 14 D x 5.25 H) |
|
Weight: |
43 kg. (95lbs.) |
|
Power Consumption: |
18 watts (for display and control circuits) |
|
Receptacles: |
Fourteen IEC C-13 (two front panel, twelve rear panel) |
