Opis
Electro-Voice RE97LTX mikrofon pojemnościowy
Dostępny w kolorze beżowym i czarnym. Mikrofon przeznaczony do zastosowań wymagających wysokiej jakości nagrań itp.Jest praktycznie niewidoczny podczas noszenia.
opis ze strony producenta:
The RE97LTx is a micro-lavalier (black and beige) omni-directional, condenser microphone designed for applications that demand a high quality microphone element that is practically invisible when worn by the speaker or performer. The RE97LTx is intended for spoken-word use in theatrical performance, fixed installations, corporate AV presentations, houses of worship, or any venue.
Ultra-Miniature Size for Inconspicuous Use
Omni-directional Polar Pattern to Provide Clean Sound and Uniform Response
Available in black and beige
Superior Sound Quality
TA4F connector is compatible with all EV bodypack transmitters
Use with TXA for wired XLR applications
Transducer:
Condenser, Back-Electret
Freq. Response: 50 Hz – 15 kHz
Polar Pattern: Omnidirectional
Sensitivity, 1 kHz: -48 dBV, 4.0 mV/Pascal
Maximum SPL:>120 dB SPL
Equivalent Noise: 32 dBA
Dynamic Range: 88 dB
Output Impedance, 1 kHz: 3000 Ohms
Power Requirements: +5 VDC
Current Consumption: 310 A
Polarity: Positive Pressure on Diaphragm Produces a Positive Voltage on Pin 2
Dimensions: See Diagram
Cable: (1.22 m) Long (1.30 mm) Diameter
TA4F Connector Wiring:
Pin 1 – Ground
Pin 2 – Audio
Pin 3 – Bias Voltage
Pin 4 – Unused
Accessories Furnished: Long and Short Windscreens Dual Clothing Clip Gig Bag
Colors Available: Black, Beige
Net Microphone Weight: 10.5 g Clip Only – 2.1 g
Optional Accessories: TXA Phantom Power Adapter
