MIPRO MI 909 R Odbiornik bezprzewodowy stereo UHF typu Body Pack
MI-909R operates in a wide 64 MHz bandwidth and it has easy to use controls and indicators with a backlit LCD screen. Advanced dual-antenna diversity design eliminates signal dropouts and enhances signal stability. Features a lightweight, exceptionally durable magnesium alloy bodypack case. Ideal for professional installations and live applications. Proprietary digital encryption provides secure audio transmission, preventing unauthorized listening in conferences, meetings and language interpretations applications.
- Ultra-compact, lightweight and rugged magnesium housing.
- 64 MHz wide bandwidth.
- Dual-antenna diversity design eliminates signal dropouts and enhances RF stability.
- lightweight, exceptionally durable magnesium alloy bodypack case.
- LCD screen displays audio & RF metering, battery status bar, group & channel, R/L balance.
- Selectable stereo, mono or mixed output mode.
- PLL-synthesized technology enables large compatible channels operation.
- ACT syncs the transmitter & receiver frequency automatically.
- Menu controls and indicators accessed by three buttons.
- S/N ratio> 95dBA (stereo receiving).
- 95dB stereo separation.
- 20 Hz ~ 15 kHz Frequency Response.
- 0.1% @ 1kHz distortion.
- Earphone output power 120mW @ 16.
- Extended operating hours with 2 AA alkaline batteries.
- Dual unbreakable soft antennas.
- Frequency Range: 480~824 MHz (country dependent)
- Bandwidth: 64 MHz
- Compatible Channels & Preset Channels: 12 compatible channels in group 1-10, 16 compatible channels in group 11-16, Testing channels in group 17, 16 user-defined channels in group 18, 216 preset channels
- Oscillation Mode: PLL-Synthesized
- Channel Grid: 25 kHz
- Frequency Stability: ± 0.005% (-10 ~ +60)
- Sensitivity: 10V input level, S/N> 90dB (Stereo)
- Modulation Mode: Digital Modulation
- Receiving Mode: Diversity Receiving
- Channel Set-Up: ACT Sync
- Spurious: < 4nW
- T.H.D: 0.1%@1 kHz
- Max. S/N ratio: 95 dBA (Stereo)
- Frequency Response: 20 Hz ~ 15 kHz (Stereo)
- Stereo Separation> 95 dB
- Volume Control 126 dB (1dB step)
- LCD Display audio & RF metering, battery status bar, group & channel, R/L balance
- Output Jack 3.5 mm Ø stereo earphone jack
- Output Power 2 × 120 mW @ (16)
- Earphone Impedance 16
- Power 2 AA Alkaline batteries
- Current Consumption Approx. 170 mA
- Operating Time Approx. 8 hours with 2 AA alkaline (stand-by)
- Dimensions (W × H × D) 63 × 82 × 23 mm
- Net Weight: Approx. 98 g excluding batteries
- Transmitter: MI-909T
- Operating Temperature: -10 ~ +60
- Note: Refer to actual product in the event of product discrepancy. Frequency range and maximum deviation comply with the regulations of different countries.
